On-site electrolytic fluorine generator as an alternative to cylinder supply.

From approximately 750 kg of F₂ per year, on-site electrolytic fluorine generator becomes operationally and economically relevant. It eliminates cylinder logistics, reduces regulatory exposure, and provides direct control over production input.

Discuss your project Request qualification questionnaire

The threshold where on-site generation makes sense.

At 750 kg/year, cylinder supply represents approximately 30 bundle deliveries per year. F₂ storage at this scale triggers ICPE classification obligations in France, with requirements that increase with the quantities present on site. Delivery frequency becomes a logistical constraint. A regulatory review — covering both F₂ and HF, which carries its own classification requirements — is a standard component of our Phase 1 assessment.

Key drivers for the transition:

  • Annual F₂ consumption above approximately 750 kg
  • F₂ storage triggering ICPE classification obligations — thresholds depend on quantities present on site and the overall hazardous substances inventory of the installation
  • HF supply infrastructure required for the electrolyzer, which carries its own regulatory obligations and must be assessed as part of the project
  • Cylinder delivery frequency becoming a supply chain risk
  • Strategic objective to control production inputs independently
Fluorine generator

An electrolyzer fluorine generator is a system, not a standalone unit.

An industrial F₂ electrolyzer operates with a potassium bifluoride (KF·HF) electrolyte at elevated temperature and requires high DC power. Successful integration requires:

  • A reliable anhydrous HF supply infrastructure
  • A dedicated DC power system: rectifier and adequate electrical capacity
  • Purpose-designed safety and abatement systems
  • Trained operators familiar with electrochemical processes and fluorine handling

The transition from cylinder supply to on-site generation is a project involving infrastructure changes, regulatory updates, and a commissioning process that cannot be compressed. A structured assessment phase is therefore a prerequisite to equipment specification.

PreviousNext

A defined path from first contact to first F₂.

  • Search Search

    Phase 1 — Assessment and Feasibility

    Priced according to project status
    • Fluorine generator production requirements: flow rate, purity, duty cycle
    • HF supply and infrastructure assessment
    • Electrical capacity review
    • Safety systems and ATEX classification audit
    • Regulatory framework analysis
    • Deliverable: assessment report and defined project scope

    This phase begins with our qualification questionnaire, sent to all prospective customers as a structured starting point.

    .

  • Tools Tools

    Phase 2 — Pre-FEED

    Scope defined on project basis
    • Electrolyzer sizing and configuration
    • HF and electrolyte management system design
    • DC power supply specification
    • Cooling system definition
    • Preliminary control and safety architecture
    • Site integration: footprint, utilities, process interfaces
    • CAPEX estimation and project execution roadmap
    • Deliverable: defined technical solution and budgetary proposal
  • Heart Heart

    Phase 3 — FEED

    Scoped after Pre-FEED acceptance
    • Detailed P&IDs and electrical schematics
    • Instrumentation and control design
    • HAZOP input
    • Procurement specifications
  • Tools Tools

    Phase 4 — Execution

    Scoped after FEED
    • Equipment supply
    • Installation support and commissioning
    • Operator training: electrolyzer operation, F₂ and HF handling
    • Safety documentation
    • Post-commissioning support and maintenance
